Aggregate batcher

● Suitable for storage 3-4 different types aggregate

● Equipped TAIWAN AIRTAC air cylinder to control the discharge gate

● Equipped HK CHIMEI load cell, guarantee the weighing accuracy

● Equipped OLI vibrator to make sure smooth feeding.

● Each bins with top screen mesh to avoid oversize aggregate

● Inside vibrating design available

Trough belt conveyor

● Up to 45 degree inclination, stand small area

● Equipped with pulling switch for emergency stop

● Equipped with spiral roller and alloy cleaner to clean the belt

● Rain cover available to reduce the dust emission and protect the belt

Aggregate Transit hopper

To make sure the continuous production , when the 1st batch mixing , the 2nd  batch weighing at the same time, more efficiency and high production.

Mixing system

● Twin-shaft compulsory mixer

● Heavy duty design and multi seal protection

● Equipped wear-resistant alloy blade and lining tile(changeable), the continuously mixing can up to 160,000 times

● With maintenance and observing gate

● Equipped with auto lubricate pump

Cement and fly ash weighing

● Adopting air vibrating system, vibrating evenly and better to protect the hopper

● 3 nos load cells to guarantee the weighing precision

● Equipped SICOMA pneumatic butterfly valve

● Reasonable permeability design can balance the pressure during filling.

Water and additive weighing

● Rough and precise weighing design to ensure the measurement accuracy

● Equipped with stainless steel tank and pump for additive to against rust and corrosion

● Equipped with Electro-pneumatically operated butterfly valve

Pneumatic system

● Equipped with TAIWAN FUSHENG air compressor

● Adopting TAIWAN AIR TAC air cylinders, valves, hoses, filters and other fittings

● Equipped with small air bag for aggregate batcher to guarantee the enough pressure

Intelligent computer control system

● Fully automatic and manual operation of the system is possible

● All cable /wire with tracking code to provide easy maintenance

● HK CHIMEI weighing indicators are equipped on control panels

● Adopting SIENMENS or SCHNEIDER relay, button, air breaker and contactor

● Full automatic concrete productions on computer inventory entry and inventory reports

● Flexible production with lots of parameters.

● Records for every batch separately.

Model

HZS150

Theoretical production（m3/hr）

150

Aggregate hopper qty

3-6

Aggregate hopper capacity（m3）

25

Aggregate weighing capability (kg)

7500

Slant belt conveyor

Trough belt

Belt conveyor capability (t/hr)

600

Cement weighing capability  (kg)

1800

Fly ash weighing capability(kg)

600

Water weighing capability (kg)

800

Additive weighing capability (kg)

50

Mixer model

MAO4500

Mixer capacity (M3)

3

Mixing type

Twin shaft

Mixing cycle (s)

72/60

Control system

Intelligent controlling (IPC+INSTRUMENT)

Discharge height (M)

≧4.0

Total power (kw)（without optional parts）

≈172

Total weight(T)（without optional parts）

55

Transportation conditions

4*40HQ Container +1*40 OT Container
